Energie
AC-ingangsfrequentie
50 - 60 Hz
AC-ingangsspanning
115 - 240 V
Gecombineerd vermogen (+12V)
1600 W
Gecombineerd vermogen (+3.3V)
150 W
Gecombineerd vermogen (+5V)
150 W
Gecombineerd vermogen (-12V)
6 W
Gecombineerd vermogen(+5Vsb)
17,5 W
Max huidige output (+3.3V)
25 A
Max huidige output (+5V)
25 A
Max huidige output (+5Vsb)
3,5 A
Max huidige output (-12V)
0,5 A
Max output current (+12V1)
40 A
Max output current (+12V2)
40 A
Max output current (+12V3)
45 A
Max output current (+12V4)
45 A
Poorten & interfaces
20+4 pins ATX power connector
1 x
Aantal PATA power aansluiters
5
ATX power connector (20+4 pin)
EPS-voedingsconnector (4+4 pin)
Lengte CPU-stroomkabel
70 cm
Lengte PCI Express-stroomkabel
60 cm
Lengte SATA-stroomkabel
500, 600, 750, 800, 900, 950, 1050 mm
Lengte stroomkabel moederbord
60 cm
Lengte stroomkabel randapparaat (Molex)
600, 750, 900, 1050 mm
Technische details
Duurzaamheidscertificaten
CCC, CE, ENERGY STAR, ErP, Federal Communications Commission (FCC), RoHS, Triman, UKCA, WEEE
Naleving van duurzaamheid
Vermogen (continu)
1600 Watt
